8020 Axial Series
Demensions: 80×80×20 mm
Bearing Type:Sleeve,Hydraulic,Ball Bearing
Function Type:FG/RD Signal,PWM pulse
Protection:Auto Restart Protection or General Options
Lead Wire:UL 1061#26AWG or Equivalent
Red Wire:Positive(+)
Black Wire:Negative(-)
Description
| MODEL NO | RATING VOLTAGE | RATED CURRENT | POWER | SPEED | AIR FLOW | STATIC PRESSURE | NOISE LEVEL | CURVE | ||
| V | A | W | RPM | CMM | CFM | MMH20 | INH20 | (dBA) | ||
| 8020S(B)VL-N(P/M)1 | 12 | 0.15 | 1.80 | 2400 | 0.685 | 24.18 | 2.03 | 0.080 | 28.1 | L |
| 8020S(B)VM-N(P/M)1 | 12 | 0.40 | 4.80 | 3600 | 1.085 | 38.32 | 4.45 | 0.175 | 37.5 | M |
| 8020S(B)VH-N(P/M)1 | 12 | 0.50 | 6.00 | 4500 | 1.294 | 45.69 | 5.97 | 0.235 | 44.2 | H |
| 8020S(B)VL-N(P/M)2 | 24 | 0.10 | 2.40 | 2400 | 0.685 | 24.18 | 2.03 | 0.080 | 28.1 | L |
| 8020S(B)VM-N(P/M)2 | 24 | 0.25 | 6.00 | 3600 | 1.085 | 38.32 | 4.45 | 0.175 | 37.5 | M |
| 8020S(B)VH-N(P/M)2 | 24 | 0.45 | 10.80 | 4500 | 1.294 | 45.69 | 5.97 | 0.235 | 44.2 | H |
